CASE: Tcomp is delivering 2 pcs. special design for T/C exhaust for a turbo charger with custom flanges and inner sleeve.
Delivery time: one pc FastTrack. 2 weeks from inquiry to shipment. Include all insulation, gaskets, nuts and bolts.
From inquiry to finished approved technical design, it took 3 days by one of our project managers.
Design data
| Size | : | DN1800 |
| Pressure | : | 0.5 bar |
| Temperature | : | 550 °C |
| Movement | : | Axial: +/- 20mm |
| Lateral: +/- 20mm | ||
| Springrate | : | Axial: 36 N/mm |
| Lateral: 392 N/mm | ||
| No. of cycles: >10,000 | ||
| Shock conditions | : | Axial: +/- 60mm |
| Lateral: +/- 38mm | ||
| No. of cycles: 10 |
Materials
| Bellow | : | 1.4541 AISI 321 |
| Flanges/inner sleve | : | S235JRG2 |
